Contemporary urban architecture Mixed-use mid-rise

A 1/160 scale model of a contemporary urban 5-story building featuring panelized facade construction, realistic urban architectural styling, multipart assembly, and Backdrop Series™ low-relief design optimized for backdrop placement and continuous streetscape scenes. Architectural features include modern glazed entry with architectural surround, recessed punched windows, space-saving flat-back footprint, a flat roof with parapet walls and rooftop mechanical penthouse structure. The assembled model measures approximately 95 x 35 x 104 mm.

Specifications

Type
Contemporary urban architecture
Scale
1/160
Roof Type
Flat parapet roof
Roof Material
EPDM/TPO membrane roofing
Siding
Panelized composite facade with smooth architectural cladding
Foundation
Concrete slab foundation
PartX (mm)Y (mm)Z (mm)
Assembly X1 94.55 35.46 103.89
Perimeter X1 #1 91.50 32.41 93.41
Wall X2 #2 20.97 93.41 1.91
Wall X1 #3 89.59 93.41 1.91
Wall X1 #4 89.59 93.41 11.44
Roof X1 #5 91.88 30.88 9.53
Base X1 #6 94.55 35.46 0.97
