KIT AJ-TADSRY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 7/12 pitch gable roof. Exterior materials include stone veneer siding with a standing seam metal roof system. The structure includes 11 windows and 4 exterior doors. Architectural features include chimney with enclosed chase. The assembled model measures approximately 160 × 151 × 76 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 11
- Exterior Doors
- 4
- Roof Type
- Gable
- Roof Pitch
- 7/12
- Roof Material
- Standing seam metal roof system
- Siding
- Stone veneer exterior siding
Features
- Chimney with enclosed chase
- double-panel door
- glass-panel door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 159.51 | 150.75 | 75.51 |
| Perimeter #1 | 147.24 | 141.98 | 31.55 |
| Wall #2 | 96.41 | 31.55 | 2.66 |
| Wall #3 | 17.53 | 31.55 | 1.75 |
| Wall #4 | 47.33 | 31.55 | 2.14 |
| Wall #5 | 68.36 | 31.55 | 2.66 |
| Wall #6 | 47.33 | 31.55 | 2.63 |
| Wall #7 | 52.59 | 31.55 | 2.66 |
| Wall #8 | 96.41 | 31.55 | 2.63 |
| Wall #9 | 138.48 | 31.55 | 2.63 |
| Roof #10 | 148.99 | 140.23 | 42.24 |
| Base #11 | 159.51 | 150.75 | 1.75 |
