KIT AJ-N3DSRY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 4/12 pitch gable roof. Exterior materials include stone veneer siding with a standing seam metal roof system. The structure includes 20 windows and a single exterior door. Architectural features include chimney with enclosed chase. The assembled model measures approximately 99 × 123 × 62 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 4
- Windows
- 20
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 4/12
- Roof Material
- Standing seam metal roof system
- Siding
- Stone veneer exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Chimney with enclosed chase
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 98.16 | 122.70 | 61.14 |
| Perimeter #1 | 75.37 | 102.51 | 35.06 |
| Wall #2 | 71.87 | 35.06 | 5.26 |
| Wall #3 | 96.41 | 35.06 | 2.63 |
| Wall #4 | 71.87 | 35.06 | 2.63 |
| Wall #5 | 96.41 | 35.06 | 2.63 |
| Roof #6 | 87.64 | 112.18 | 24.36 |
| Base #7 | 98.16 | 122.70 | 1.75 |
