KIT AJ-C8DSRY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 6/12 pitch hip roof. Exterior materials include stone veneer siding with a standing seam metal roof system. The structure includes 14 windows and 5 exterior doors. Architectural features include an overhead garage door, chimney with enclosed chase. The assembled model measures approximately 206 × 172 × 73 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 14
- Exterior Doors
- 5
- Roof Type
- Hip
- Roof Pitch
- 6/12
- Roof Material
- Standing seam metal roof system
- Siding
- Stone veneer exterior siding
Features
- Chimney with enclosed chase
- double-panel door
- overhead garage door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 205.09 | 171.78 | 72.30 |
| Perimeter #1 | 189.31 | 155.13 | 31.55 |
| Wall #2 | 99.91 | 31.55 | 2.66 |
| Wall #3 | 14.02 | 31.55 | 1.75 |
| Wall #4 | 85.89 | 31.55 | 2.14 |
| Wall #5 | 68.36 | 31.55 | 2.66 |
| Wall #6 | 85.89 | 31.55 | 1.75 |
| Wall #7 | 70.11 | 31.55 | 2.66 |
| Wall #8 | 99.91 | 31.55 | 1.75 |
| Wall #9 | 152.50 | 31.55 | 2.63 |
| Roof #10 | 194.57 | 161.26 | 39.03 |
| Base #11 | 205.09 | 171.78 | 1.75 |
