KIT AJ-A4DSRY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 6/12 pitch gable roof. Exterior materials include stone veneer siding with a standing seam metal roof system. The structure includes 12 windows and a single exterior door. Architectural features include chimney with enclosed chase. The assembled model measures approximately 113 × 127 × 67 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 6
- Windows
- 12
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 6/12
- Roof Material
- Standing seam metal roof system
- Siding
- Stone veneer exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Chimney with enclosed chase
- double-panel door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 112.18 | 126.21 | 66.46 |
| Perimeter #1 | 103.42 | 120.04 | 35.06 |
| Wall #2 | 78.88 | 35.06 | 5.26 |
| Wall #3 | 28.05 | 35.06 | 2.63 |
| Wall #4 | 21.03 | 35.06 | 2.63 |
| Wall #5 | 85.89 | 35.06 | 2.63 |
| Wall #6 | 99.91 | 35.06 | 2.63 |
| Wall #7 | 113.94 | 35.06 | 2.63 |
| Roof #8 | 101.67 | 115.69 | 29.68 |
| Base #9 | 112.18 | 126.21 | 1.75 |
