KIT AH-5AR5RY
Architecture / House
Manual
Multifamily two-story House
A 1/87 scale model of a multifamily two-story-style house. It features a 4/12 pitch gable roof. Exterior materials include vinyl or wood siding with a standing seam metal roof system. The structure includes 24 windows and 3 exterior doors. Architectural features include balcony with guardrail, a side addition, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 127 × 210 × 97 mm.
Specifications
- Type
- Multifamily two-story
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 24
- Exterior Doors
- 3
- Roof Type
- Gable
- Roof Pitch
- 4/12
- Roof Material
- Standing seam metal roof system
- Siding
- Vinyl or wood exterior siding
Features
- Side addition
- balcony with guardrail
- chimney with enclosed chase
- double-panel door
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 126.21 | 209.64 | 96.55 |
| Perimeter #1 | 115.69 | 204.39 | 63.10 |
| Wall #2 | 113.94 | 63.10 | 11.60 |
| Wall #3 | 36.81 | 63.10 | 1.75 |
| Wall #4 | 19.28 | 63.10 | 1.75 |
| Wall #5 | 78.88 | 63.10 | 1.75 |
| Wall #6 | 19.28 | 63.10 | 1.79 |
| Wall #7 | 77.13 | 63.10 | 1.75 |
| Wall #8 | 113.94 | 63.10 | 1.75 |
| Wall #9 | 192.82 | 63.10 | 1.75 |
| Roof #10 | 115.69 | 194.57 | 31.73 |
| Base #11 | 126.21 | 205.09 | 1.75 |
| Balcony #12 | 77.13 | 19.28 | 1.75 |
| Guardrail #13 | 77.09 | 14.02 | 1.75 |
