Multifamily two-story House
A 1/87 scale model of a multifamily two-story-style house. It features a 5/12 pitch gable roof. Exterior materials include vinyl or wood siding with a standing seam metal roof system. The structure includes 32 windows and 3 exterior doors. Architectural features include balcony with guardrail, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 120 × 160 × 100 mm.
Specifications
- Type
- Multifamily two-story
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 32
- Exterior Doors
- 3
- Roof Type
- Gable
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Vinyl or wood exterior siding
Features
- Balcony with guardrail
- chimney with enclosed chase
- double-panel door
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 119.20 | 159.51 | 99.32 |
| Perimeter #1 | 101.67 | 148.99 | 63.10 |
| Wall #2 | 99.91 | 63.10 | 1.79 |
| Wall #3 | 57.84 | 63.10 | 1.75 |
| Wall #4 | 19.28 | 63.10 | 1.75 |
| Wall #5 | 47.33 | 63.10 | 1.75 |
| Wall #6 | 19.28 | 63.10 | 1.79 |
| Wall #7 | 42.07 | 63.10 | 1.75 |
| Wall #8 | 99.91 | 63.10 | 1.75 |
| Wall #9 | 147.24 | 63.10 | 1.75 |
| Roof #10 | 108.68 | 148.99 | 34.50 |
| Base #11 | 119.20 | 159.51 | 1.75 |
| Balcony #12 | 45.57 | 19.28 | 1.75 |
| Guardrail #13 | 45.54 | 14.02 | 1.75 |
