KIT AH-1JUFRY
Architecture / House
Manual
Multifamily two-story House
A 1/87 scale model of a multifamily two-story-style house. It features a 7/12 pitch gable roof. Exterior materials include vinyl or wood siding with a standing seam metal roof system. The structure includes 26 windows and 3 exterior doors. Architectural features include covered front porch, balcony with guardrail, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 137 × 211 × 115 mm.
Specifications
- Type
- Multifamily two-story
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 26
- Exterior Doors
- 3
- Roof Type
- Gable
- Roof Pitch
- 7/12
- Roof Material
- Standing seam metal roof system
- Siding
- Vinyl or wood exterior siding
Features
- Covered front porch
- balcony with guardrail
- chimney with enclosed chase
- double-panel door
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 136.72 | 210.34 | 114.95 |
| Perimeter #1 | 119.20 | 192.11 | 63.10 |
| Wall #2 | 117.44 | 63.10 | 11.60 |
| Wall #3 | 36.81 | 63.10 | 1.75 |
| Wall #4 | 19.28 | 63.10 | 1.75 |
| Wall #5 | 63.10 | 63.10 | 1.75 |
| Wall #6 | 19.28 | 63.10 | 1.79 |
| Wall #7 | 80.63 | 63.10 | 1.75 |
| Wall #8 | 117.44 | 63.10 | 1.75 |
| Wall #9 | 180.55 | 63.10 | 1.75 |
| Roof #10 | 126.21 | 199.83 | 50.13 |
| Base #11 | 136.72 | 210.34 | 1.75 |
| Railing #12 | 15.78 | 63.10 | 1.75 |
| Railing #13 | 15.78 | 63.10 | 1.75 |
| Balcony #14 | 61.35 | 19.28 | 1.75 |
| Guardrail #15 | 61.31 | 14.02 | 1.75 |
