KIT AG-0GS5RY
Architecture / House
Manual
Two-story House
A 1/87 scale model of a two-story-style house. It features a 5/12 pitch gable roof. Exterior materials include vinyl or wood siding with a standing seam metal roof system. The structure includes 34 windows and 3 exterior doors. Architectural features include covered front porch, an attached garage, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 195 × 123 × 90 mm.
Specifications
- Type
- Two-story
- Scale
- 1/87
- Wall Panels
- 14
- Windows
- 34
- Exterior Doors
- 3
- Roof Type
- Gable
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Vinyl or wood exterior siding
Features
- Covered front porch
- attached garage
- chimney with enclosed chase
- double-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 194.57 | 122.70 | 89.83 |
| Perimeter #1 | 184.05 | 87.64 | 52.59 |
| Wall #2 | 43.82 | 52.59 | 1.75 |
| Wall #3 | 12.27 | 52.59 | 1.75 |
| Wall #4 | 54.34 | 52.59 | 1.79 |
| Wall #5 | 12.27 | 52.59 | 1.75 |
| Wall #6 | 43.82 | 52.59 | 1.75 |
| Wall #7 | 14.02 | 52.59 | 1.75 |
| Wall #8 | 40.32 | 52.59 | 1.79 |
| Wall #9 | 71.87 | 52.59 | 1.75 |
| Wall #10 | 40.32 | 52.59 | 1.75 |
| Wall #11 | 12.27 | 52.59 | 1.75 |
| Wall #12 | 22.79 | 52.59 | 1.79 |
| Wall #13 | 12.27 | 52.59 | 1.75 |
| Wall #14 | 119.20 | 52.59 | 1.75 |
| Wall #15 | 85.89 | 52.59 | 1.75 |
| Roof #16 | 184.05 | 112.18 | 35.52 |
| Base #17 | 194.57 | 122.70 | 1.75 |
| Railing #18 | 15.78 | 52.59 | 1.75 |
| Railing #19 | 15.78 | 52.59 | 1.75 |
