Two-story House
A 1/87 scale model of a two-story-style house. It features a 7/12 pitch gable roof. Exterior materials include brick veneer siding with a standing seam metal roof system. The structure includes 25 windows and 2 exterior doors. Architectural features include a side addition, chimney with enclosed chase. The assembled model measures approximately 163 × 121 × 107 mm.
Specifications
- Type
- Two-story
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 25
- Exterior Doors
- 2
- Roof Type
- Gable
- Roof Pitch
- 7/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Side addition
- chimney with enclosed chase
- double-panel door
- glass-panel door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 162.32 | 120.25 | 106.63 |
| Perimeter #1 | 154.43 | 115.86 | 61.35 |
| Wall #2 | 99.91 | 61.35 | 11.60 |
| Wall #3 | 25.07 | 61.35 | 2.63 |
| Wall #4 | 42.07 | 61.35 | 2.63 |
| Wall #5 | 57.32 | 61.35 | 11.60 |
| Wall #6 | 42.07 | 61.35 | 2.63 |
| Wall #7 | 21.03 | 61.35 | 2.63 |
| Wall #8 | 99.91 | 61.35 | 2.63 |
| Wall #9 | 103.42 | 61.35 | 2.63 |
| Roof #10 | 147.24 | 105.17 | 43.56 |
| Base #11 | 157.76 | 115.69 | 1.75 |
