KIT AF-44U5RY
Architecture / House
Manual
A 1/87 scale model of a two-story-style house. It features a 5/12 pitch gable roof. Exterior materials include brick veneer siding with a standing seam metal roof system. The structure includes 20 windows and a single exterior door. Architectural features include covered front porch, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 116 × 235 × 86 mm.
Specifications
- Type
- Two-story
- Scale
- 1/87
- Wall Panels
- 6
- Windows
- 20
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Covered front porch
- chimney with enclosed chase
- double-panel door
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 115.69 | 234.89 | 85.15 |
| Perimeter #1 | 106.93 | 211.19 | 56.09 |
| Wall #2 | 82.39 | 56.09 | 5.26 |
| Wall #3 | 52.59 | 56.09 | 2.63 |
| Wall #4 | 21.03 | 56.09 | 2.63 |
| Wall #5 | 152.50 | 56.09 | 2.63 |
| Wall #6 | 103.42 | 56.09 | 2.63 |
| Wall #7 | 205.09 | 56.09 | 2.63 |
| Roof #8 | 105.17 | 224.37 | 27.34 |
| Base #9 | 115.69 | 234.89 | 1.75 |
| Railing #10 | 15.78 | 56.09 | 1.75 |
| Railing #11 | 15.78 | 56.09 | 1.75 |
