KIT AF-2XT5RY
Architecture / House
Manual
Two-story House
A 1/87 scale model of a two-story-style house. It features a 8/12 pitch hip roof. Exterior materials include brick veneer siding with a standing seam metal roof system. The structure includes 26 windows and a single exterior door. Architectural features include a side addition, chimney with enclosed chase. The assembled model measures approximately 142 × 159 × 104 mm.
Specifications
- Type
- Two-story
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 26
- Exterior Doors
- 1
- Roof Type
- Hip
- Roof Pitch
- 8/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Side addition
- chimney with enclosed chase
- double-panel door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 141.98 | 158.81 | 103.85 |
| Perimeter #1 | 133.22 | 154.43 | 61.35 |
| Wall #2 | 89.40 | 61.35 | 11.60 |
| Wall #3 | 35.06 | 61.35 | 2.63 |
| Wall #4 | 40.32 | 61.35 | 2.63 |
| Wall #5 | 89.40 | 61.35 | 2.63 |
| Wall #6 | 40.32 | 61.35 | 2.63 |
| Wall #7 | 17.53 | 61.35 | 1.75 |
| Wall #8 | 89.40 | 61.35 | 2.63 |
| Wall #9 | 141.98 | 61.35 | 2.63 |
| Roof #10 | 131.47 | 143.74 | 40.78 |
| Base #11 | 141.98 | 154.25 | 1.75 |
