KIT AF-2JT5RY
Architecture / House
Manual
Two-story House
A 1/87 scale model of a two-story-style house. It features a 5/12 pitch gable roof. Exterior materials include brick veneer siding with a standing seam metal roof system. The structure includes 22 windows and a single exterior door. Architectural features include covered front porch, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 123 × 186 × 86 mm.
Specifications
- Type
- Two-story
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 22
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Covered front porch
- chimney with enclosed chase
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 122.70 | 185.80 | 85.15 |
| Perimeter #1 | 106.93 | 158.60 | 56.09 |
| Wall #2 | 75.37 | 56.09 | 5.26 |
| Wall #3 | 56.09 | 56.09 | 2.63 |
| Wall #4 | 14.02 | 56.09 | 1.75 |
| Wall #5 | 96.41 | 56.09 | 2.63 |
| Wall #6 | 103.42 | 56.09 | 2.63 |
| Wall #7 | 96.41 | 56.09 | 2.63 |
| Wall #8 | 14.02 | 56.09 | 1.75 |
| Wall #9 | 56.09 | 56.09 | 2.63 |
| Roof #10 | 112.18 | 175.29 | 27.34 |
| Base #11 | 122.70 | 185.80 | 1.75 |
| Railing #12 | 15.78 | 56.09 | 1.75 |
| Railing #13 | 15.78 | 56.09 | 1.75 |
