KIT AF-1VS5RY
Featured
Architecture / House
Manual
A 1/87 scale model of a two-story-style house. It features a 6/12 pitch gable roof. Exterior materials include brick veneer siding with a standing seam metal roof system. The structure includes 34 windows and 4 exterior doors. Architectural features include an attached garage, chimney with enclosed chase. The assembled model measures approximately 220 × 113 × 91.00 mm.
Specifications
- Type
- Two-story
- Scale
- 1/87
- Wall Panels
- 14
- Windows
- 34
- Exterior Doors
- 4
- Roof Type
- Gable
- Roof Pitch
- 6/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer exterior siding
Features
- Attached garage
- chimney with enclosed chase
- double-panel door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 219.11 | 112.18 | 91.00 |
| Perimeter #1 | 210.34 | 96.41 | 52.59 |
| Wall #2 | 41.72 | 52.59 | 2.63 |
| Wall #3 | 12.27 | 52.59 | 1.75 |
| Wall #4 | 51.53 | 52.59 | 2.66 |
| Wall #5 | 12.27 | 52.59 | 1.75 |
| Wall #6 | 41.72 | 52.59 | 2.63 |
| Wall #7 | 14.02 | 52.59 | 1.75 |
| Wall #8 | 71.87 | 52.59 | 2.66 |
| Wall #9 | 78.88 | 52.59 | 2.63 |
| Wall #10 | 71.87 | 52.59 | 2.63 |
| Wall #11 | 12.27 | 52.59 | 1.75 |
| Wall #12 | 22.79 | 52.59 | 2.66 |
| Wall #13 | 12.27 | 52.59 | 1.75 |
| Wall #14 | 112.18 | 52.59 | 2.63 |
| Wall #15 | 92.90 | 52.59 | 2.63 |
| Roof #16 | 208.59 | 101.67 | 36.69 |
| Base #17 | 219.11 | 112.18 | 1.75 |
