KIT AE-9WSFRY
Architecture / House
Manual
Two-story House
A 1/87 scale model of a two-story-style house. It features a 8/12 pitch gable roof. Exterior materials include engineered log siding with a standing seam metal roof system. The structure includes 26 windows and 5 exterior doors. Architectural features include an overhead garage door, chimney with enclosed chase. The assembled model measures approximately 193 × 145 × 104 mm.
Specifications
- Type
- Two-story
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 26
- Exterior Doors
- 5
- Roof Type
- Gable
- Roof Pitch
- 8/12
- Roof Material
- Standing seam metal roof system
- Siding
- Engineered log exterior siding
Features
- Attached garage
- chimney with enclosed chase
- double-panel door
- overhead garage door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 192.11 | 144.79 | 103.27 |
| Perimeter #1 | 183.35 | 139.53 | 57.84 |
| Wall #2 | 89.40 | 57.84 | 11.60 |
| Wall #3 | 17.53 | 57.84 | 1.75 |
| Wall #4 | 82.39 | 57.84 | 1.79 |
| Wall #5 | 68.36 | 57.84 | 11.60 |
| Wall #6 | 82.39 | 57.84 | 1.75 |
| Wall #7 | 42.07 | 57.84 | 11.60 |
| Wall #8 | 89.40 | 57.84 | 1.75 |
| Wall #9 | 127.96 | 57.84 | 1.75 |
| Roof #10 | 177.04 | 129.71 | 43.70 |
| Base #11 | 187.56 | 140.23 | 1.75 |
