KIT AD-16R5RY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 6/12 pitch gable roof. Exterior materials include engineered log siding with a standing seam metal roof system. The structure includes 10 windows and 2 exterior doors. Architectural features include a side addition, chimney with enclosed chase. The assembled model measures approximately 141 × 124 × 76 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 10
- Exterior Doors
- 2
- Roof Type
- Gable
- Roof Pitch
- 6/12
- Roof Material
- Standing seam metal roof system
- Siding
- Engineered log exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Side addition
- chimney with enclosed chase
- glass-panel door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 140.23 | 123.75 | 75.22 |
| Perimeter #1 | 115.69 | 118.49 | 36.81 |
| Wall #2 | 85.89 | 36.81 | 11.60 |
| Wall #3 | 24.54 | 36.81 | 1.75 |
| Wall #4 | 28.05 | 36.81 | 1.75 |
| Wall #5 | 57.84 | 36.81 | 1.75 |
| Wall #6 | 28.05 | 36.81 | 11.60 |
| Wall #7 | 24.54 | 36.81 | 1.75 |
| Wall #8 | 85.89 | 36.81 | 1.75 |
| Wall #9 | 106.93 | 36.81 | 1.75 |
| Roof #10 | 129.71 | 108.68 | 36.69 |
| Base #11 | 140.23 | 119.20 | 1.75 |
