Ranch House
A 1/87 scale model of a ranch-style house. It features a 8/12 pitch hip roof. Exterior materials include engineered log siding with a standing seam metal roof system. The structure includes 15 windows and 2 exterior doors. Architectural features include covered front porch, a side addition, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 176 × 190 × 89 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 15
- Exterior Doors
- 2
- Roof Type
- Hip
- Roof Pitch
- 8/12
- Roof Material
- Standing seam metal roof system
- Siding
- Engineered log exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Covered front porch
- side addition
- chimney with enclosed chase
- double-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 175.29 | 189.31 | 88.66 |
| Perimeter #1 | 157.76 | 161.23 | 31.55 |
| Wall #2 | 117.44 | 31.55 | 5.26 |
| Wall #3 | 21.03 | 31.55 | 1.75 |
| Wall #4 | 38.56 | 31.55 | 1.75 |
| Wall #5 | 113.94 | 31.55 | 1.75 |
| Wall #6 | 38.56 | 31.55 | 5.26 |
| Wall #7 | 21.03 | 31.55 | 1.75 |
| Wall #8 | 117.44 | 31.55 | 1.75 |
| Wall #9 | 156.01 | 31.55 | 1.75 |
| Roof #10 | 164.77 | 178.79 | 55.39 |
| Base #11 | 175.29 | 189.31 | 1.75 |
| Railing #12 | 15.78 | 31.55 | 1.75 |
| Railing #13 | 15.78 | 31.55 | 1.75 |
