Ranch House
A 1/87 scale model of a ranch-style house. It features a 5/12 pitch gable roof. Exterior materials include brick veneer lower with vinyl or wood upper siding with a standing seam metal roof system. The structure includes 13 windows and a single exterior door. Architectural features include covered front porch, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 123 × 197 × 61 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 6
- Windows
- 13
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer lower with vinyl or wood upper exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Covered front porch
- chimney with enclosed chase
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 122.70 | 196.32 | 60.61 |
| Perimeter #1 | 112.18 | 171.75 | 31.55 |
| Wall #2 | 82.39 | 31.55 | 5.26 |
| Wall #3 | 42.07 | 31.55 | 1.75 |
| Wall #4 | 28.05 | 31.55 | 1.75 |
| Wall #5 | 124.45 | 31.55 | 1.75 |
| Wall #6 | 110.43 | 31.55 | 1.75 |
| Wall #7 | 166.52 | 31.55 | 1.75 |
| Roof #8 | 112.18 | 185.80 | 27.34 |
| Base #9 | 122.70 | 196.32 | 1.75 |
| Railing #10 | 15.78 | 31.55 | 1.75 |
| Railing #11 | 15.78 | 31.55 | 1.75 |
