KIT AC-47Q5RY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 4/12 pitch hip roof. Exterior materials include brick veneer lower with vinyl or wood upper siding with a standing seam metal roof system. The structure includes 15 windows and 3 exterior doors. Architectural features include covered front porch, an attached garage, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 172 × 162 × 58 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 10
- Windows
- 15
- Exterior Doors
- 3
- Roof Type
- Hip
- Roof Pitch
- 4/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer lower with vinyl or wood upper exterior siding
Features
- Covered front porch
- attached garage
- chimney with enclosed chase
- double-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 171.78 | 161.26 | 57.99 |
| Perimeter #1 | 154.25 | 129.71 | 28.05 |
| Wall #2 | 92.90 | 28.05 | 1.79 |
| Wall #3 | 35.06 | 28.05 | 1.75 |
| Wall #4 | 59.60 | 28.05 | 1.79 |
| Wall #5 | 92.90 | 28.05 | 1.75 |
| Wall #6 | 57.84 | 28.05 | 1.75 |
| Wall #7 | 12.27 | 28.05 | 1.75 |
| Wall #8 | 47.33 | 28.05 | 1.79 |
| Wall #9 | 12.27 | 28.05 | 1.75 |
| Wall #10 | 47.33 | 28.05 | 1.75 |
| Wall #11 | 127.96 | 28.05 | 1.75 |
| Roof #12 | 161.26 | 150.75 | 28.22 |
| Base #13 | 171.78 | 161.26 | 1.75 |
| Railing #14 | 15.78 | 28.05 | 1.75 |
| Railing #15 | 15.78 | 28.05 | 1.75 |
