KIT AC-1JP5RY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 8/12 pitch gable roof. Exterior materials include brick veneer lower with vinyl or wood upper siding with a standing seam metal roof system. The structure includes 12 windows and a single exterior door. Architectural features include covered front porch, a side addition, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 148 × 144 × 73 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 12
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 8/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer lower with vinyl or wood upper exterior siding
Features
- Covered front porch
- side addition
- chimney with enclosed chase
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 147.24 | 143.74 | 72.01 |
| Perimeter #1 | 136.72 | 115.69 | 28.05 |
| Wall #2 | 92.90 | 28.05 | 1.79 |
| Wall #3 | 25.24 | 28.05 | 1.75 |
| Wall #4 | 42.07 | 28.05 | 1.75 |
| Wall #5 | 71.17 | 28.05 | 1.75 |
| Wall #6 | 42.07 | 28.05 | 1.75 |
| Wall #7 | 17.53 | 28.05 | 1.75 |
| Wall #8 | 92.90 | 28.05 | 1.75 |
| Wall #9 | 113.94 | 28.05 | 1.75 |
| Roof #10 | 136.72 | 133.22 | 42.24 |
| Base #11 | 147.24 | 143.74 | 1.75 |
| Railing #12 | 15.78 | 28.05 | 1.75 |
| Railing #13 | 15.78 | 28.05 | 1.75 |
