KIT AC-1CQ5RY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 8/12 pitch gable roof. Exterior materials include brick veneer lower with vinyl or wood upper siding with a standing seam metal roof system. The structure includes 22 windows and 2 exterior doors. Architectural features include covered front porch, a side addition, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 164 × 176 × 83 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 22
- Exterior Doors
- 2
- Roof Type
- Gable
- Roof Pitch
- 8/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer lower with vinyl or wood upper exterior siding
Features
- Covered front porch
- side addition
- chimney with enclosed chase
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 163.02 | 175.29 | 82.23 |
| Perimeter #1 | 145.49 | 147.24 | 28.05 |
| Wall #2 | 103.42 | 28.05 | 1.79 |
| Wall #3 | 43.30 | 28.05 | 1.75 |
| Wall #4 | 40.32 | 28.05 | 1.75 |
| Wall #5 | 77.65 | 28.05 | 1.79 |
| Wall #6 | 40.32 | 28.05 | 1.75 |
| Wall #7 | 24.54 | 28.05 | 1.75 |
| Wall #8 | 103.42 | 28.05 | 1.75 |
| Wall #9 | 145.49 | 28.05 | 1.75 |
| Roof #10 | 152.50 | 164.77 | 52.47 |
| Base #11 | 163.02 | 175.29 | 1.75 |
| Railing #12 | 15.78 | 28.05 | 1.75 |
| Railing #13 | 15.78 | 28.05 | 1.75 |
