KIT AC-1ANDRY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 4/12 pitch gable roof. Exterior materials include brick veneer lower with vinyl or wood upper siding with a standing seam metal roof system. The structure includes 9 windows and a single exterior door. Architectural features include window shutters, chimney with enclosed chase. The assembled model measures approximately 123 × 165 × 70 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 4
- Windows
- 9
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 4/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer lower with vinyl or wood upper exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Chimney with enclosed chase
- glass-panel door
- window shutters
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 122.70 | 164.77 | 69.38 |
| Perimeter #1 | 98.86 | 150.40 | 36.81 |
| Wall #2 | 96.41 | 36.81 | 11.60 |
| Wall #3 | 138.48 | 36.81 | 2.10 |
| Wall #4 | 96.41 | 36.81 | 2.10 |
| Wall #5 | 138.48 | 36.81 | 2.10 |
| Roof #6 | 112.18 | 154.25 | 30.85 |
| Base #7 | 122.70 | 164.77 | 1.75 |
