Ranch House
A 1/87 scale model of a ranch-style house. It features a 6/12 pitch hip roof. Exterior materials include brick veneer lower with vinyl or wood upper siding with a standing seam metal roof system. The structure includes 13 windows and 2 exterior doors. Architectural features include covered front porch, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 169 × 127 × 72 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 13
- Exterior Doors
- 2
- Roof Type
- Hip
- Roof Pitch
- 6/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer lower with vinyl or wood upper exterior siding
Features
- Covered front porch
- chimney with enclosed chase
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 168.28 | 126.21 | 71.13 |
| Perimeter #1 | 150.75 | 94.66 | 28.05 |
| Wall #2 | 45.93 | 28.05 | 1.75 |
| Wall #3 | 12.27 | 28.05 | 1.75 |
| Wall #4 | 57.14 | 28.05 | 1.79 |
| Wall #5 | 12.27 | 28.05 | 1.75 |
| Wall #6 | 45.93 | 28.05 | 1.75 |
| Wall #7 | 92.90 | 28.05 | 1.75 |
| Wall #8 | 148.99 | 28.05 | 1.79 |
| Wall #9 | 92.90 | 28.05 | 1.75 |
| Roof #10 | 157.76 | 115.69 | 41.37 |
| Base #11 | 168.28 | 126.21 | 1.75 |
| Railing #12 | 15.78 | 28.05 | 1.75 |
| Railing #13 | 15.78 | 28.05 | 1.75 |
