KIT AC-0GQ5RY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 4/12 pitch gable roof. Exterior materials include brick veneer lower with vinyl or wood upper siding with a standing seam metal roof system. The structure includes 11 windows and 2 exterior doors. Architectural features include window shutters, chimney with enclosed chase. The assembled model measures approximately 148 × 202 × 66 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 6
- Windows
- 11
- Exterior Doors
- 2
- Roof Type
- Gable
- Roof Pitch
- 4/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer lower with vinyl or wood upper exterior siding
Features
- Chimney with enclosed chase
- glass-panel door
- window shutters
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 147.24 | 201.93 | 65.87 |
| Perimeter #1 | 123.40 | 201.93 | 33.30 |
| Wall #2 | 96.41 | 33.30 | 11.60 |
| Wall #3 | 49.08 | 33.30 | 2.10 |
| Wall #4 | 24.54 | 33.30 | 1.75 |
| Wall #5 | 131.47 | 33.30 | 2.10 |
| Wall #6 | 120.95 | 33.30 | 11.60 |
| Wall #7 | 180.55 | 33.30 | 2.10 |
| Roof #8 | 136.72 | 182.30 | 30.85 |
| Base #9 | 147.24 | 192.82 | 1.75 |
