KIT AC-0BQ5RY
Featured
Architecture / House
Manual
A 1/87 scale model of a ranch-style house. It features a 5/12 pitch hip roof. Exterior materials include brick veneer lower with vinyl or wood upper siding with a standing seam metal roof system. The structure includes 14 windows and 4 exterior doors. Architectural features include an overhead garage door, window shutters, chimney with enclosed chase. The assembled model measures approximately 260 × 247 × 71 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 10
- Windows
- 14
- Exterior Doors
- 4
- Roof Type
- Hip
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer lower with vinyl or wood upper exterior siding
Features
- Attached garage
- chimney with enclosed chase
- double-panel door
- overhead garage door
- window shutters
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 259.43 | 246.45 | 70.55 |
| Perimeter #1 | 242.60 | 238.04 | 33.30 |
| Wall #2 | 103.42 | 33.30 | 11.60 |
| Wall #3 | 122.70 | 33.30 | 2.10 |
| Wall #4 | 136.72 | 33.30 | 1.79 |
| Wall #5 | 103.42 | 33.30 | 2.10 |
| Wall #6 | 49.08 | 33.30 | 1.75 |
| Wall #7 | 12.27 | 33.30 | 1.75 |
| Wall #8 | 138.48 | 33.30 | 11.60 |
| Wall #9 | 12.27 | 33.30 | 1.75 |
| Wall #10 | 52.59 | 33.30 | 2.10 |
| Wall #11 | 226.12 | 33.30 | 2.10 |
| Roof #12 | 248.91 | 234.89 | 35.52 |
| Base #13 | 259.43 | 245.40 | 1.75 |
