KIT AC-00NDRY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 5/12 pitch gable roof. Exterior materials include brick veneer lower with vinyl or wood upper siding with a standing seam metal roof system. The structure includes 14 windows and a single exterior door. Architectural features include covered front porch, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 130 × 169 × 65 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 4
- Windows
- 14
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer lower with vinyl or wood upper exterior siding
Features
- Covered front porch
- chimney with enclosed chase
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 129.71 | 168.28 | 64.27 |
| Perimeter #1 | 105.17 | 126.21 | 28.05 |
| Wall #2 | 103.42 | 28.05 | 1.79 |
| Wall #3 | 124.45 | 28.05 | 1.75 |
| Wall #4 | 103.42 | 28.05 | 1.75 |
| Wall #5 | 124.45 | 28.05 | 1.75 |
| Roof #6 | 119.20 | 157.76 | 34.50 |
| Base #7 | 129.71 | 168.28 | 1.75 |
| Railing #8 | 15.78 | 28.05 | 1.75 |
| Railing #9 | 15.78 | 28.05 | 1.75 |
