KIT AB-4YMDRY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 4/12 pitch gable roof. Exterior materials include brick veneer siding with a standing seam metal roof system. The structure includes 8 windows and a single exterior door. Architectural features include covered front porch, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 85 × 137 × 58 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 4
- Windows
- 8
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 4/12
- Roof Material
- Standing seam metal roof system
- Siding
- Brick veneer exterior siding
Features
- Covered front porch
- chimney with enclosed chase
- double-panel door
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 84.14 | 136.72 | 57.46 |
| Perimeter #1 | 68.36 | 103.42 | 31.55 |
| Wall #2 | 64.86 | 31.55 | 2.66 |
| Wall #3 | 99.91 | 31.55 | 2.63 |
| Wall #4 | 64.86 | 31.55 | 2.63 |
| Wall #5 | 99.91 | 31.55 | 2.63 |
| Roof #6 | 73.62 | 126.21 | 24.19 |
| Base #7 | 84.14 | 136.72 | 1.75 |
| Railing #8 | 15.78 | 31.55 | 1.75 |
| Railing #9 | 15.78 | 31.55 | 1.75 |
