KIT AA-2TM5RY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 6/12 pitch gable roof. Exterior materials include vinyl or wood siding with a standing seam metal roof system. The structure includes 12 windows and 2 exterior doors. Architectural features include chimney with enclosed chase. The assembled model measures approximately 158 × 120 × 73 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 12
- Exterior Doors
- 2
- Roof Type
- Gable
- Roof Pitch
- 6/12
- Roof Material
- Standing seam metal roof system
- Siding
- Vinyl or wood exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Chimney with enclosed chase
- double-panel door
- glass-panel door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 157.76 | 119.20 | 72.30 |
| Perimeter #1 | 147.24 | 98.13 | 31.55 |
| Wall #2 | 44.87 | 31.55 | 1.75 |
| Wall #3 | 12.27 | 31.55 | 1.75 |
| Wall #4 | 55.74 | 31.55 | 5.26 |
| Wall #5 | 12.27 | 31.55 | 1.75 |
| Wall #6 | 44.87 | 31.55 | 1.75 |
| Wall #7 | 92.90 | 31.55 | 1.75 |
| Wall #8 | 145.49 | 31.55 | 5.26 |
| Wall #9 | 92.90 | 31.55 | 1.75 |
| Roof #10 | 147.24 | 108.68 | 39.03 |
| Base #11 | 157.76 | 119.20 | 1.75 |
