KIT AA-0JM5RY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 7/12 pitch hip roof. Exterior materials include vinyl or wood siding with a standing seam metal roof system. The structure includes 18 windows and 2 exterior doors. Architectural features include covered front porch, a side addition, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 169 × 151 × 80 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 18
- Exterior Doors
- 2
- Roof Type
- Hip
- Roof Pitch
- 7/12
- Roof Material
- Standing seam metal roof system
- Siding
- Vinyl or wood exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Covered front porch
- side addition
- chimney with enclosed chase
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 168.28 | 150.75 | 79.46 |
| Perimeter #1 | 157.72 | 122.67 | 31.55 |
| Wall #2 | 106.93 | 31.55 | 5.26 |
| Wall #3 | 33.48 | 31.55 | 1.75 |
| Wall #4 | 45.57 | 31.55 | 1.75 |
| Wall #5 | 66.43 | 31.55 | 5.26 |
| Wall #6 | 45.57 | 31.55 | 1.75 |
| Wall #7 | 17.53 | 31.55 | 1.75 |
| Wall #8 | 106.93 | 31.55 | 1.75 |
| Wall #9 | 117.44 | 31.55 | 1.75 |
| Roof #10 | 157.76 | 140.23 | 46.19 |
| Base #11 | 168.28 | 150.75 | 1.75 |
| Railing #12 | 15.78 | 31.55 | 1.75 |
| Railing #13 | 15.78 | 31.55 | 1.75 |
