Ranch House
A 1/87 scale model of a ranch-style house. It features a 5/12 pitch hip roof. Exterior materials include stone veneer siding with a standing seam metal roof system. The structure includes 15 windows and 2 exterior doors. Architectural features include chimney with enclosed chase. The assembled model measures approximately 172 × 130 × 75 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 15
- Exterior Doors
- 2
- Roof Type
- Hip
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Stone veneer exterior siding
- Foundation
- Crawl space or basement foundation
Features
- Chimney with enclosed chase
- glass-panel door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 171.78 | 129.71 | 74.35 |
| Perimeter #1 | 156.01 | 116.53 | 35.06 |
| Wall #2 | 46.98 | 35.06 | 2.63 |
| Wall #3 | 12.27 | 35.06 | 1.75 |
| Wall #4 | 58.55 | 35.06 | 5.26 |
| Wall #5 | 12.27 | 35.06 | 1.75 |
| Wall #6 | 46.98 | 35.06 | 2.63 |
| Wall #7 | 110.43 | 35.06 | 2.63 |
| Wall #8 | 152.50 | 35.06 | 5.26 |
| Wall #9 | 110.43 | 35.06 | 2.63 |
| Roof #10 | 161.26 | 119.20 | 37.57 |
| Base #11 | 171.78 | 129.71 | 1.75 |
