KIT AJ-8ADSRY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 4/12 pitch hip roof. Exterior materials include stone veneer siding with a standing seam metal roof system. The structure includes 14 windows and 3 exterior doors. Architectural features include covered front porch, an overhead garage door, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 192 × 127 × 65.00 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 14
- Windows
- 14
- Exterior Doors
- 3
- Roof Type
- Hip
- Roof Pitch
- 4/12
- Roof Material
- Standing seam metal roof system
- Siding
- Stone veneer exterior siding
Features
- Covered front porch
- chimney with enclosed chase
- double-panel door
- glass-panel door
- overhead garage door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 191.06 | 126.21 | 65.00 |
| Perimeter #1 | 182.30 | 99.91 | 31.55 |
| Wall #2 | 42.77 | 31.55 | 1.75 |
| Wall #3 | 12.27 | 31.55 | 1.75 |
| Wall #4 | 52.94 | 31.55 | 2.14 |
| Wall #5 | 12.27 | 31.55 | 1.75 |
| Wall #6 | 42.77 | 31.55 | 2.63 |
| Wall #7 | 14.02 | 31.55 | 1.75 |
| Wall #8 | 40.32 | 31.55 | 2.14 |
| Wall #9 | 82.39 | 31.55 | 2.63 |
| Wall #10 | 40.32 | 31.55 | 2.63 |
| Wall #11 | 12.27 | 31.55 | 1.75 |
| Wall #12 | 22.79 | 31.55 | 2.14 |
| Wall #13 | 12.27 | 31.55 | 1.75 |
| Wall #14 | 115.69 | 31.55 | 2.63 |
| Wall #15 | 96.41 | 31.55 | 2.63 |
| Roof #16 | 180.55 | 115.69 | 31.73 |
| Base #17 | 191.06 | 126.21 | 1.75 |
| Railing #18 | 15.78 | 31.55 | 1.75 |
| Railing #19 | 15.78 | 31.55 | 1.75 |
