KIT AH-01S5RY
Architecture / House
Manual
Multifamily two-story House
A 1/87 scale model of a multifamily two-story-style house. It features a 5/12 pitch hip roof. Exterior materials include vinyl or wood siding with a standing seam metal roof system. The structure includes 29 windows and 4 exterior doors. Architectural features include balcony with guardrail, a side addition, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 156 × 175 × 99 mm.
Specifications
- Type
- Multifamily two-story
- Scale
- 1/87
- Wall Panels
- 12
- Windows
- 29
- Exterior Doors
- 4
- Roof Type
- Hip
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Vinyl or wood exterior siding
Features
- Side addition
- balcony with guardrail
- chimney with enclosed chase
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 155.30 | 174.59 | 98.30 |
| Perimeter #1 | 150.05 | 169.33 | 63.10 |
| Wall #2 | 103.42 | 63.10 | 18.62 |
| Wall #3 | 47.33 | 63.10 | 1.75 |
| Wall #4 | 19.28 | 63.10 | 1.75 |
| Wall #5 | 47.33 | 63.10 | 1.75 |
| Wall #6 | 19.28 | 63.10 | 1.79 |
| Wall #7 | 56.09 | 63.10 | 1.75 |
| Wall #8 | 103.42 | 63.10 | 1.75 |
| Wall #9 | 33.30 | 63.10 | 1.75 |
| Wall #10 | 28.05 | 63.10 | 1.75 |
| Wall #11 | 82.39 | 63.10 | 18.62 |
| Wall #12 | 28.05 | 63.10 | 1.75 |
| Wall #13 | 35.06 | 63.10 | 1.75 |
| Roof #14 | 133.22 | 152.50 | 33.48 |
| Base #15 | 143.74 | 163.02 | 1.75 |
| Balcony #16 | 45.57 | 19.28 | 1.75 |
| Guardrail #17 | 45.54 | 14.02 | 1.75 |
