KIT AG-2US5RY
Architecture / House
Manual
Two-story House
A 1/87 scale model of a two-story-style house. It features a 6/12 pitch gable roof. Exterior materials include vinyl or wood siding with a standing seam metal roof system. The structure includes 22 windows and a single exterior door. Architectural features include chimney with enclosed chase. The assembled model measures approximately 123 × 135 × 90 mm.
Specifications
- Type
- Two-story
- Scale
- 1/87
- Wall Panels
- 8
- Windows
- 22
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 6/12
- Roof Material
- Standing seam metal roof system
- Siding
- Vinyl or wood exterior siding
Features
- Chimney with enclosed chase
- double-panel door
- glass-panel door
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 122.70 | 134.27 | 89.71 |
| Perimeter #1 | 105.17 | 129.01 | 57.84 |
| Wall #2 | 61.35 | 57.84 | 18.62 |
| Wall #3 | 35.06 | 57.84 | 1.75 |
| Wall #4 | 21.03 | 57.84 | 1.75 |
| Wall #5 | 75.37 | 57.84 | 1.75 |
| Wall #6 | 103.42 | 57.84 | 1.75 |
| Wall #7 | 75.37 | 57.84 | 1.75 |
| Wall #8 | 21.03 | 57.84 | 1.75 |
| Wall #9 | 35.06 | 57.84 | 1.75 |
| Roof #10 | 112.18 | 115.69 | 30.15 |
| Base #11 | 122.70 | 126.21 | 1.75 |
