KIT AA-15M5RY
Architecture / House
Manual
Ranch House
A 1/87 scale model of a ranch-style house. It features a 5/12 pitch gable roof. Exterior materials include vinyl or wood siding with a standing seam metal roof system. The structure includes 12 windows and a single exterior door. Architectural features include covered front porch, support posts and railings, chimney with enclosed chase. The assembled model measures approximately 141 × 221 × 64 mm.
Specifications
- Type
- Ranch
- Scale
- 1/87
- Wall Panels
- 6
- Windows
- 12
- Exterior Doors
- 1
- Roof Type
- Gable
- Roof Pitch
- 5/12
- Roof Material
- Standing seam metal roof system
- Siding
- Vinyl or wood exterior siding
Features
- Covered front porch
- chimney with enclosed chase
- glass-panel door
- support posts and railings
| Part | X (mm) | Y (mm) | Z (mm) |
|---|---|---|---|
| Assembly | 140.23 | 220.86 | 63.24 |
| Perimeter #1 | 129.71 | 192.82 | 28.05 |
| Wall #2 | 103.42 | 28.05 | 1.79 |
| Wall #3 | 31.55 | 28.05 | 1.75 |
| Wall #4 | 24.54 | 28.05 | 1.75 |
| Wall #5 | 159.51 | 28.05 | 1.75 |
| Wall #6 | 127.96 | 28.05 | 1.75 |
| Wall #7 | 191.06 | 28.05 | 1.75 |
| Roof #8 | 129.71 | 210.34 | 33.48 |
| Base #9 | 140.23 | 220.86 | 1.75 |
| Railing #10 | 15.78 | 28.05 | 1.75 |
| Railing #11 | 15.78 | 28.05 | 1.75 |
